DC Regulated Power Supply 0-32V
The DC Regulated Power Supply 0-32V is designed for precise and stable power delivery across a wide range of applications. It offers a maximum output voltage of 32 volts and provides adjustable output for versatility in testing and powering electronic components. Key features include:
- Output Voltage Range: 0-32V DC
- Current Limiting: Adjustable to protect connected devices from overcurrent.
- High Precision: Ensures stable and accurate voltage output.
- Display: Digital display for easy monitoring of voltage and current.
- Cooling System: Efficient heat dissipation to ensure reliable performance during prolonged use.
**DC Power Supply Can Be Made As Per Customer Specification**
CES 500
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 20A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT(MAX) |
|---|---|---|
| CES - 500 | 0 - 32V | 0 - 20A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION(CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION(CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION(CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION(CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 501
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 10A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 501 | 0 - 32V | 0 - 10A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 501-50
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 50A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 501-50 | 0 - 32V | 0 - 50A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 2 mV |
| COOLING | : | Force Air Cooling |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 502
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 5A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 502 | 0 - 32V | 0 - 5A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 503
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 2A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 503 | 0 - 32V | 0 - 2A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 504
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 1A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 504 | 0 - 32V | 0 - 1A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
CES 505
DC REGULATED POWER SUPPLY 0 - 32V / 0 - 30A
“CROWN” offer best in class constant voltage constant current DC Regulated Power Supply using linear technology offering all kind of protections with specification and features to meet customer requirements. Our power supply offer stabilized output voltage With low ripple in wide input variation of ±10% with full protection against Short Circuit & over load using fold back technology.
| CODE | OUTPUT VOLTAGE | OUTPUT CURRENT (MAX) |
|---|---|---|
| CES - 504 | 0 - 32V | 0 - 30A |
| INPUT VOLTAGE | : | 230V ± 10% AC 50 Hz |
| OUTPUT VOLTAGE | : | Continuously Variable with Coarse & Fine Control |
| OUTPUT CURRENT | : | Settable with Coarse & Fine Control |
| LOAD REGULATION (CV) | : | ± 0.05% ± 3mV From no load to full load |
| LOAD REGULATION (CC) | : | ± 0.05% ± 1mA From no load to full load |
| LINE REGULATION (CV) | : | ± 0.01% ± 3mV for ±10% variation input voltage |
| LINE REGULATION (CC) | : | ± 0.01% ± 1mA for ±10% variation input voltage |
| RIPPLE | : | 1 mV |
| METER | : | Two Digital meters to monitor the output voltage & current |
| PROTECTION | : | Against short circuit & over load |
DC Regulated Power Supply 0-32V
DC Regulated Power Supply 0-32V is a precise and versatile instrument designed to provide accurate voltage control for laboratories, research centers, educational institutions, and industrial applications. This adjustable DC power supply 0-32V delivers stable, low-noise output, making it ideal for electronics testing, circuit development, and experimental projects. The digital display DC power supply allows users to monitor voltage and current easily, while built-in short circuit protection and overload protection keep both the device and connected circuits safe.
Engineers, technicians, and students rely on this bench power supply 0-32V to test LED drivers, microcontrollers, and other electronic components. Its compact, durable design suits DIY projects, electronic laboratories, and industrial setups. The programmable DC power supply 0-32V lets users adjust voltage and current precisely, supporting single-channel or dual-channel applications. Known for its high precision, reliability, and advanced technology, this 0-32V DC regulated power supply is a preferred choice for professionals who need consistent performance, safety, and accuracy in their work.
